Male Connector

Male Connector Product Details

The Male Connector is a high-performance fluid and gas transmission fitting designed for industrial pneumatic systems, vacuum applications, and inert gas delivery. Engineered for reliability, safety, and long service life, it is widely used in compressed air systems and industrial pipeline networks.

Product Overview

The Male Connector is suitable for connecting pipeline systems transporting compressed air, vacuum, and inert gases such as helium, nitrogen, and argon. It is designed to ensure stable sealing performance under demanding working conditions, making it ideal for industrial, civil, and specialized applications.

Technical Parameters

Medium Compatibility:
Compressed air, vacuum, inert gases (helium, nitrogen, argon, etc.)

Working Pressure:
Up to 16 bar

Working Temperature Range:
-20℃ to +80℃ / -60℃ to +180℃ (depending on material configuration)

Material Options:
Sprayed aluminum, stainless steel, engineering plastics

Product Specifications

Male Connector models are available in multiple nominal diameters and thread combinations to meet different installation requirements:

DN20-R1/2" (Assembled) — W 48 mm × H 79.5 mm
DN20-R3/4" (Assembled) — W 48 mm × H 79.5 mm

DN25-R1/2" (Assembled) — W 53 mm × H 79.5 mm
DN25-R3/4" (Assembled) — W 53 mm × H 79.5 mm
DN25-R1" (Assembled) — W 53 mm × H 79.5 mm

DN20-R1/2" — W 48 mm × H 79.5 mm
DN20-R3/4" — W 48 mm × H 79.5 mm

DN25-R1/2" — W 53 mm × H 79.5 mm
DN25-R3/4" — W 53 mm × H 79.5 mm
DN25-R1" — W 53 mm × H 79.5 mm

DN40-R1" — W 52.5 mm × H 72 mm
DN40-R1 1/2" — W 59 mm × H 80 mm

DN50-R1 1/2" — W 59 mm × H 80 mm
DN50-R2" — W 70.9 mm × H 80 mm

DN65-R2" — W 79.5 mm × H 100 mm
DN65-R2 1/2" — W 88.2 mm × H 102 mm

DN80-R2 1/2" — W 97.9 mm × H 102 mm
DN80-R3" — W 102.3 mm × H 107 mm

Product Features

The Male Connector is designed with advanced manufacturing and surface treatment technologies to ensure excellent performance in industrial environments:

• High-pressure resistance up to 16 bar

• Strong sealing performance for air and gas systems

• Corrosion-resistant material options for extended service life

• Suitable for wide temperature environments

• Precision machining for stable and leak-free connection

• Compatible with multiple pipeline systems

Application Fields

The Male Connector is widely used in:

• Compressed air systems

• Industrial vacuum systems

• Gas transmission systems (nitrogen, helium, argon, etc.)

• Manufacturing and automation equipment

• Industrial piping and fluid control systems

• Civil and commercial pipeline installations
