Tiger Pro 60HC 460-480 Watt

Jinko 470W–490W Half-Cut Monocrystalline Solar Panels for High-Efficiency Energy Systems

Product Specifications

Cell Type: P-Type Monocrystalline Silicon

Number of Cells: 120 (6 × 20)

Dimensions: 1903 × 1134 × 30 mm (74.92 × 44.65 × 1.18 inches)

Weight: 24.2 kg (53.35 lbs)

Front Glass: 3.2 mm tempered glass with anti-reflective coating, high light transmission, and low-iron composition

Frame: Anodized aluminum alloy

Junction Box: IP68-rated protection

Output Cables: TÜV-certified 1 × 4.0 mm² cables; positive cable length of 400 mm and negative cable length of 200 mm, with customized lengths available

Product Description

The Jinko 470W–490W half-cut monocrystalline solar panels are designed for solar energy systems that require dependable power output, efficient space utilization, and durable module construction. Available in multiple power ratings, these panels provide flexible options for residential, commercial, and industrial photovoltaic installations, subject to the specifications of the selected model.

Continuous development in PERC solar cell technology has helped improve photovoltaic conversion efficiency and module performance while supporting more cost-effective solar power generation. Half-cut cell designs divide conventional solar cells into smaller sections, helping reduce resistive losses and improve electrical performance under suitable operating conditions.

The panels feature a low-iron tempered glass front with an anti-reflective coating to support light transmission, while the anodized aluminum alloy frame provides structural support. An IP68-rated junction box offers protection against dust and water ingress under its specified test conditions, contributing to the module's suitability for outdoor solar installations.

With a compact 30 mm profile and a weight of 24.2 kg, the module can be incorporated into appropriately designed mounting systems. Standardized output cable specifications and customizable cable lengths also provide flexibility during system integration.

For buyers evaluating the Jinko Tiger Pro 60HC solar panel series, selecting the appropriate wattage requires checking the exact model datasheet, including electrical output, operating conditions, dimensions, and installation requirements. These details help ensure compatibility with the inverter, mounting structure, and overall photovoltaic system design.
