HDI PCB with Microvias for High-Density Compact Electronics
HDI PCBs with microvias are designed for ultra-high circuit density and compact layouts.
HDI PCB with Microvias – Compact and High-Density Solutions
Introduction
Our HDI PCBs with microvias are designed to achieve ultra-high circuit density for compact electronic devices. Microvias enable precise multi-layer connections with minimal board area, supporting miniaturized and lightweight electronics. These PCBs offer excellent electrical performance, high signal integrity, and reliable operation in demanding applications.
Key Features
-
Ultra-high-density circuit design for miniaturized devices
-
Microvia technology for precise layer-to-layer connections
-
Excellent signal integrity and low EMI
-
Reliable and stable electrical performance
-
Supports compact, lightweight, and portable electronics
-
Customizable copper thickness, board size, and surface finish
Specifications
-
Base Material: FR-4, High TG options
-
Board Thickness: 0.4–1.6 mm
-
Copper Thickness: 1/2 oz, 1 oz, 2 oz
-
Min. Line/Spacing: 0.08 mm / 0.08 mm
-
Min. Hole Size: 0.1 mm
-
Via Type: Microvias
-
Surface Finish: ENIG, OSP, Lead-free HASL
-
Flexibility: Rigid or flexible PCB
-
Applications: High-density electronics, compact devices
Packing & Delivery
-
Each PCB packed in anti-static bag
-
Protected with bubble wrap or foam
-
Carton box with fragile label
-
Quantity per carton as requested
-
Label shows part number and lot
-
Ship by air, sea, or courier
-
Store dry, avoid sunlight and humidity
Why Choose Our HDI PCB
-
Advanced microvia technology for ultra-compact boards
-
High precision and reliable signal performance
-
Suitable for miniaturized and portable electronics
-
Supports prototype to mass production volumes
-
Professional support for global electronic clients
