HAKRC 50A F4 Fly Tower
HAKRC 45A F4V2 flying tower is equipped with BLS 45A four-in-one ESC and F405 flight control, Installation hole spacing of 30.5 * 30.5mm.
HAKRC 50A F4V2 flying tower is equipped with BLS 45A four-in-one ESC and F405 flight control, Installation hole spacing of 30.5 * 30.5mm.F405 flight controller is equipped with 5 UARTs, MPU6500 IMU, OSD, F.Port and many other functions!Built-in plug-in allows you to easily connect to the DJI FPV Air System.Integrated 16Mb black box, barometer, upgraded Type-C USB interface, greatly improve socket life and reduce the risk of poor contact. Supports various receivers including Sbus,ELRS， PPM, CRSF, DSMX, iBus, DUMD, etc.
F405 FC Specifications：
Size: 36 * 36mm (30.5mm-30.5mm mounting hole)
Packaging size: 64 * 64 * 35mm
Input voltage: 2S-6S Lipo
Net weight of product: 8.5g
Packaging weight: 40g
CPU: STM32F405RET6
IMU: ICM42688
OSD: AT7456E
Barometer: integrated
Black box: 16M
BEC: 5V/3A
BEC: 10V/2.5A
LED: Comes with four programmable LED illusion lights
Sensor: built-in current sensor
Firmware version: HAKRCF405V2
Receiver: Frsky/Futaba/Flysky/TBS Crossfire/DSMX: DSM2 receiver
BLS 45A ESC Specifications：
Size: 44 * 44mm (20/30.mm-20/30.5mm mounting hole)
Packaging size: 64 * 64 * 35mm
Net weight of product: 13.5g
Packaging weight: 52g
Input voltage: 2S-6S Lipo
Galvanometer ratio: 160
Continuous current: 45A
Peak current: 50A
Electric adjustment firmware: G_ H_ 40- Rev. 16.7- Multi
Protocol support: PWM, Oneshot125, Oneshot42, Multispot, Dshot150, Dshot300, Dshot600
