5050RGB-10/120D-24V-20mm

Schematic diagram of the control wiring

（1）One output port can carry load points (segments)

Example: 1 meter 6 section RGB soft light belt, a channel can drive how many pixels

The recommended band load less than 70% pixels

（2）Do、GND lines correspond to A / D +,connected to the output end of the controller GND。 (refer to Figure 1).

Figure 1

（3）Output terminal of the controller, the end distance to the string lamp strip, the longest distance is recommended not to exceed 100M, If this distance is exceeded, a signal amplifier should be used.(Refer to Figure 2)

Figure 2

Precautions

1. In the process of installation and debugging, attention should be paid to the positive and negative poles of the power supply can not be connected to the wrong connection, to avoid the live insertion and disassembly of the input and output line of the light strip, otherwise the light strip may be damaged;

2. The light strip shall be powered by low-voltage isolated power supply, and the output ripple of the power supply is <5%. Do not use resistance type step-down, non-isolated power supply or directly connected to the mains drive light strip, otherwise it may cause damage to the light bar or personal injury;

3. Before installation, please test the light belt with the controller and control system to ensure the compatibility of the light belt and the controller and control system

FAQ:

1. Payment by TT (Telegraphic Transfer).

2. Three – year warranty.

3. We accept light customization (such as length customization, waterproof customization, and packaging customization).

4. Transportation methods: sea freight, air freight, and land transportation.
