1000V DC Extension Cable with U Shape Contact
Model#: PK10-JT173A
Desc.: Extension Cable with U Shape Contact
https://www.parko-solar.com/1000V-DC-Extension-Cable-with-U-Shape-Contact.html
Products Main Features:
1. High voltage & current endurance capability; use for 1000V system;
2. Good impact resistance & ageing resistance capability; use imported PPO raw material;
3. Lower contact resistance to 0.30 mΩ, contact material: pure copper (99.9%);
4. Innovative seal & waterproof design, meet IP67
5. High performance for ambient temperature range from -40℃ ~ +85℃, UV resistance, insulation, suitable for long time outdoor use.
6. Good safety performance, TUV test & approved, sell well in Euro & US.
7. Easy & quick for installation, high pull-out force, stable self-locking structure, long working life above to 20 years.
8. Compatible with MC4, EVO2, QC4 etc. PV connectors.
9. cable spec. & lenght TBC by customer
Specification (Main Technical Parameters):
Rated current | 20A~30A | Insulation material | Sabic PPO |
Rated voltage | 1000V(IEC)/600V(UL) | Material RTI | 110℃ |
Test voltage | 6KV(50Hz.1min) | Ambient temperature range | -40℃~+85℃ |
Contact resistance | ≤0.5mΩ | Suitable wire size range | 2.5mm2~6mm2 (14~10AWG) |
Contact material | Copper.Tin plated | PV Cable length | User defined |
Flame class | UL94-V0 | PV Cable Color | Black/Red |
Products Main Size:
Product Application Diagram:
